Dispenser Mode, Backfeed After Printing with External Control (Release) Input, with Media Sensor Enabled, and with Pulse Input

Operation

• The figure above shows the reference position when the Gap sensor is used. • If [Interface] > [External I/O] > [Print Start Signal] > [Feed] is enabled, PRIN (Print Start) signal will operate as the FEED signal. For this reason, backfeed will be executed without waiting for PRIN (Print Start) signal. • Even if [Interface] > [External I/O] > [Print Start Signal] > [Signal State] is set to Falling edge or Rising edge, the signal detection at backfeed is equivalent to Low active or High active.

Timing Chart (Without Head Check)

Timing Chart (With Head Check)

*1 If throughput mode is enabled, it will be 7.5ms.

*2 Backfeed will be executed when the PRIN (Print Start) signal is OFF at the completion of printing.
