Linerless Mode, Backfeed Before Printing, with Media Sensor Disabled, and with Pulse Input

Operation

*1 Feeds distance set for [Backfeed Offset]

*2 Actual print size in vertical direction

*3 Feeds total of distance set for [Feed Offset] and size specified by the End Position <EP> command

• The spaces between each layout varies depending on the print speed. In the figure above, as you set the print speed faster, the space between the first and second print becomes wider. • You can set the [Feed Offset] and [Backfeed Offset] in the [Printing] > [Advanced] menu.

Timing Chart (Without Head Check)

Timing Chart (With Head Check)

*1 Keep the PRIN (Print Start) signal until the PREND (Print End) signal is outputted.

• Do feeding while pressing the button in the Offline mode. However, the PREND (Print End) signal will not change.

---
